Category: Inductors, Coils, Chokes
                  Fixed Inductors
Mfr: Abracon LLC
Series: AISC-0805
Packaging: Tape & Reel (TR)
                     Cut Tape (CT)
                     Digi-Reel®
Part Status: Active
Type: Drum Core, Wirewound
Material – Core: Ceramic
Inductance: 100 nH
Tolerance: ±2%
Current Rating (Amps): 400 mA
Current – Saturation (Isat): –
Shielding: Unshielded
DC Resistance (DCR): 460mOhm Max
Q @ Freq: 50 @ 500MHz
Frequency – Self Resonant: 1.2GHz
Ratings: –
Operating Temperature: -40°C ~ 125°C
Inductance Frequency – Test: 150 MHz
Mounting Type: Surface Mount
Package / Case: 0805 (2012 Metric)
Supplier Device Package: 0805
Size / Dimension: 0.090″ L x 0.068″ W (2.29mm x 1.73mm)
Height – Seated (Max): 0.061″ (1.55mm)
