Category: Isolators
                  Digital Isolators
Mfr: Analog Devices Inc.
Series: iCoupler®
Packaging: Tape & Reel (TR)
                     Cut Tape (CT)
                     Digi-Reel®
Part Status: Active
Technology: Magnetic Coupling
Type: General Purpose
Isolated Power: No
Number of Channels: 4
Inputs – Side 1/Side 2: 3/1
Channel Type: Unidirectional
Voltage – Isolation: 3000Vrms
Common Mode Transient Immunity (Min): 75kV/µs
Data Rate: 150Mbps
Propagation Delay tpLH / tpHL (Max): 13ns, 13ns
Pulse Width Distortion (Max): 3ns
Rise / Fall Time (Typ): 2.5ns, 2.5ns
Voltage – Supply: 1.7V ~ 5.5V
Operating Temperature: -40°C ~ 125°C
Mounting Type: Surface Mount
Package / Case: 16-SSOP (0.154″, 3.90mm Width)
Supplier Device Package: 16-QSOP
Base Product Number: ADUM141
